L11
Dimensions |
|
| A | 7 070 mm |
| B | 3 000 mm |
| C | 1 555 mm |
| D | 440 mm |
| E | 4 070 mm |
| F | 2 745 mm |
| G | 1 075 mm |
| H | 3 280 mm |
| I | 2 475 mm |
| J | 2 620 mm |
| R1 | 4 920 mm |
| R2 | 5 515 mm |
L11
Ljungby L11 is a strong machine with high capacity. It is longer, heavier and stronger than Ljungby L9, but still quick and flexible! Winner of the latest test, presented in the Swedish industry magazine Boggi, comparing wheel loaders in the 11 ton class from the market leading manufacturers.
dimensions
specifications
L11 - Tier 4F engine
Drive line
| Engine | Sisu 66 AWF |
| Max power (kW/hp) | 151/205 |
| Max torque (Nm) | 943 |
| Gearbox | ZF Ergopower WG160 |
| Front axle | ZF MTL 3075 |
| Rear axle | ZF MTL 3075 |
| Automatic limited slip rear | s |
| Automatic/manual diff lock front | s |
| Dual-circuit hydraulic foot brake | s |
| Hydraulic operated parking brake | s |
| Lock-up transmission | o |
| Reversible fan | o |
|
s = standard |
Power and weight
| Breakout force (kN) | 95 |
| Tipping load (kg) | 0° 8 100 |
| 40° 6 950 | |
| 45° 6 550 | |
| Operating weight (tons) | 10,9-11,5 |
| Standard bucket (m3) | 2,1 |
| Light material bucket (m3) | 5,0 |
| Timber grapple (m2) | 1,6 |
Hydraulic system
| Hydraulic Pump | Parker |
| Flow (l/min at 2300 rpm) | 220 |
| Pressure (bar) | 250 |
| Lift cylinder (mm) | 56/100 |
| Lift cylinder stroke (mm) | 850 |
| Tilt cylinder (mm) | 56/100 |
| Tilt cylinder stroke (mm) | 895 |
| Hydraulic cooling | s |
Electrical system
| Battery | 2 x 12 V, 120 A |
| Alternator | 100 A |
Steering system
| Steering angle (degrees) | 45 |
| Steering cylinder (mm) | 40/70 |
| Steering cylinder stroke (mm) | 557 |
| Oscillating rear axle (degrees) | +/- 15 |
Capacity information
| Cooling system (l) | 30 |
| Engine (l) | 29 |
| Hydraulic system (l) | 175 |
| Fuel tank (l) | 200 |
| Ad Blue tanl (l) | 60 |
Wheels
| Radial tyres | s |
| Dimensions | 20,5R25 |
L11 - Tier IIIA engine and lock-up
Drive line
| Engine | Sisu 66 AWF |
| Max power (kW/hp) | 170/231 |
| Max torque (Nm) | 950 |
| Gearbox | ZF Ergopower WG160 |
| Front axle | ZF MTL 3075 |
| Rear axle | ZF MTL 3075 |
| Automatic limited slip rear | s |
| Automatic/manual diff lock front | s |
| Dual-circuit hydraulic foot brake | s |
| Hydraulic operated parking brake | s |
| Lock-up transmission | s |
| Reversible fan | o |
|
s = standard |
Power and weight
| Breakout force (kN) | 95 |
| Tipping load (kg) | 0° 8 100 |
| 40° 6 950 | |
| 45° 6 550 | |
| Operating weight (tons) | 10,9-11,5 |
| Standard bucket (m3) | 2,1 |
| Light material bucket (m3) | 5,0 |
| Timber grapple (m2) | 1,6 |
Hydraulic system
| Hydraulic Pump | Parker |
| Flow (l/min at 2300 rpm) | 220 |
| Pressure (bar) | 250 |
| Lift cylinder (mm) | 56/100 |
| Lift cylinder stroke (mm) | 850 |
| Tilt cylinder (mm) | 56/100 |
| Tilt cylinder stroke (mm) | 895 |
| Hydraulic cooling | s |
Electrical system
| Battery | 2 x 12 V, 120 A |
| Alternator | 100 A |
Steering system
| Steering angle (degrees) | 45 |
| Steering cylinder (mm) | 40/70 |
| Steering cylinder stroke (mm) | 557 |
| Oscillating rear axle (degrees) | +/- 15 |
Capacity information
| Cooling system (l) | 30 |
| Engine (l) | 29 |
| Hydraulic system (l) | 175 |
| Fuel tank (l) | 200 |
| Ad blue tank (l) | 60 |
Wheels
| Radial tyres | s |
| Dimensions | 20,5R25 |
